36-inch range dimensions and cutout size
Going bigger? A 36-inch range changes the cabinet opening, side walls and hood.
Short answer: a "36-inch" range is actually about 35⅞ in wide and goes into a 36 in cabinet opening at a standard 36 in countertop height.[1 · Oct 29, 2026; 2 · Oct 28, 2026] Depth and clearances vary a lot between standard and pro-style models, so confirm with the install guide for the range you pick.
Range dimensions from published specs
| Measurement | Electrolux 36" dual fuel[1 · Oct 29, 2026] | Café 36" commercial-style dual fuel[2 · Oct 28, 2026] |
|---|---|---|
| Width | 35⅞ in | 35⅞ in |
| Minimum opening | 36¹⁄₁₆ in | 36 in |
| Cooking-surface height | 35¾ to 36¾ in (adjustable) | 35¼ to 36¾ in (adjustable) |
| Overall height | 41⅝ to 42⅝ in | 35¼ in |
| Depth | 27½ in to front of range | 29⅜ in without handle; 31⅛ in overall |
| Depth with oven door open | 47⅜ in | 48¼ in |
| Countertop height | 36 in standard (35¾ in min) | not listed |
Cabinet and clearance checklist
- Opening width: plan on at least 36 in between cabinets; one model asks for 36¹⁄₁₆ in.[1 · Oct 29, 2026]
- Side walls: clearances to a wall or tall cabinet beside the range differ by model: 9 in minimum on one, 12 in on each side on the pro-style model.[1 · Oct 29, 2026; 2 · Oct 28, 2026]
- Upper cabinets beside the range: one guide asks for at least 18 in from countertop to cabinet bottom and limits those cabinets to 13 in deep.[1 · Oct 29, 2026] The pro-style model also asks for 18 in over adjacent work areas.[2 · Oct 28, 2026]
- Above the cooktop: for its 36 in model the Electrolux guide asks for at least 34 in from the cooking surface to an unprotected wood or metal cabinet (28 in only if the cabinet bottom is shielded as described); its 30 in model needs 30 in (24 in shielded).[1 · Oct 29, 2026] The Café pro-style range needs 48 in to combustibles if there is no hood, and its hood's own instructions apply when there is one.[2 · Oct 28, 2026]
- Power and gas: the Café dual fuel model needs a gas supply plus a dedicated 208/240 V, 30-amp circuit.[2 · Oct 28, 2026]
- Walking room: allow about 4 ft in front for the open oven door (47⅜ to 48¼ in from the wall on these two models).[1 · Oct 29, 2026; 2 · Oct 28, 2026]
Affiliate links: if you buy through a link in this box we may earn a commission, at no extra cost to you. It does not change the sizes or sources on this page. How we handle affiliate links.
Downsizing or comparing? See 30-inch range dimensions.
Sources: 1. Electrolux, 30" and 36" dual fuel range installation instructions (PDF) (side, upper-cabinet and overhead clearances re-checked Oct 29, 2026). 2. GE Appliances, Café 36" smart dual-fuel commercial-style range spec sheet (PDF). Checked Oct 28, 2026. Trademarks belong to their owners; specs are restated, not reproduced.
